• 120w Flexible solar panels dimension - 1170mm X 540mm
  • Flexible solar panels 50/ 100/ 120w
  • Flexible_solar_panels_50w Dimension - 820mm X 370mm
  • 100w Flexible_solar_panels Dimension - 1060mm X 530mm
  • 18v_Flexible_solar_panels Background image
  • 18v_Flexible_solar_panels Wide application use
  • 18v_Flexible_solar_panels Dimension - 1090mm X 277mm
  • 18v_Flexible_solar_panels with controller
1 4

BOGUANG

18v Flexible solar panels 50/ 100/ 120w solar - 12v battery charger waterproof

18v Flexible solar panels 50/ 100/ 120w solar - 12v battery charger waterproof

$222.81 CAD
$0.00 CAD $222.81 CAD
Oferta Agotado
Los gastos de envío se calculan en la pantalla de pago.
Color
Ships From
C$2.00 coupon code if delayed

Refund if package lost - items damaged - no delivery in 35 days
  • CE
  • FCC
  • ROHS
  • WEEE

SPECIFICATIONS



Brand Name: BOGUANG

Number of Panels: 1

Flexible Solar Panel: Yes

Foldable Solar Panel: No

High-concerned Chemical: None

Type: Solar Panel

Module Efficiency: 24%

Model: Flexible Solar Panels

Material: Monocrystalline Silicon

Nominal Capacity: 18V /19.8V

Number of Cells: 36 solar cell

Max. Power: 50W / 120W /120W

Customisable: Yes

50W Flexible Solar Panel: 19.8V 50W

100W Flexible Solar Panel: 19.8V 100W

120W Flexible Solar Panel: 18v 120W



Dimensions:

50W Flexible Solar Panel size: 820x370x3mm

100W Flexible Solar Panel size: 1060x530x3mm

120W Flexible Solar Panel size: 1170x540x3mm

Solar Panel: Semi-Flexible

16V 50W Flexible Solar Panel size: 1090*277*3mm



Features:

  • Conversion efficiency 21%.
  • Generate electricity all day in the sun.
  • Can be used for fish tank circulation system, monitoring group, household photovoltaic energy storage
  • Lightweight and easy to install.
  •  Outdoor photovoltaic power generation portable device.
  • Wide range of compatibility: sailboats, yachts, marine applications, motorhomes, expedition vehicles, commercial trucks, caravans, off-grid and telematics sites, etc.


19.8V 50W Specification:

Cell material: Monocrystalline silicon
Pmax (Power at Maximum under STC):50W
Imp (Current at Max Power, A): 2.52A
Vmp(Voltage at Max Power, V): 19.8V
Voc(Voltage at Open Circuit): 21.8V
Isc (Current at Short Circuit, A): 2.65A
Solar Cell Efficiency: 24%
Size of module: 820*370*3mm

Net Weight: 2.56Ib (1.1kg)
Length of Cables: 50.038cm

19.8V 100W Specifications

Maximum power(Pmax)                           100W
Output tolerance                                  ± 3%
Maximum system voltage                       700V DC
Open circuit voltage(Voc)                        23.7V
Short circuit current(Isc)                          5.55A
Maximum power voltage(Vmp)              19.8V
Maximum power current(Imp)                 5.05A
Cell efficiency                                        24%
Operating temperature(NOCT)          45±2℃
Temperature range                                 -40℃～+80℃
Number of cells                                      33pcs
Weight                                              1950g
Size                                              1060*530*3 mm
Colour: Black
Standard Test Conditions: Irradiance 1000w/m2,Temperature 25℃,AM=1.5

18V 120W Specification

Maximum Power(Pmax): 120W

Output Tolerance: ± 3%

Maximum System Voltage: 700V DC

Open Circuit Voltage(Voc): 21.6V

Maximum Power Voltage(Vmp): 18V

Short Circuit Current(Isc) 6.8 A

Maximum Power Current(Imp) 6.5A

Cell Efficiency: 21%

Operating Temperature(NOCT): 45±2℃

Temperature Range: -40℃～+80℃

Number Of Cells: 36pcs

Weight: 2100g

Size: 1170*540*2.5 mm
Standard Test Conditions： Irradiance 1000w/m2，Temperature 25℃,AM=1.5
